WGS3 Layer 3 Switch User’s Manual
- 182 -
MD5 Key Table When use MD5 authentication mode, you have to specify an active
MD5 key on this table. Up to 8 key can be added on the table but
only one can be Active. The others should be left to be Valid. To
remove the key, set the status to be Invalid and select <Apply>. Each
key consists of two parameters:
Key ID : An identifier from 1 to 255.
Key : An alphanumeric password of up to 16 bytes.
1: The Area ID is used to specify a group of contiguous networks and hosts. OSPF protocol broadcast
messages are restricted by area to limit their impact on network performance.
2: This value must be the same for all routers attached to a common network.
