WGS3 Layer 3 Switch User’s Manual
- 170 -
are attaching to is VLAN-aware), and configure an IP interface for this VLAN if you need to connect it to
other group.
This parameter is for WGS3-2620 only. WGS3-404’s default setting is Rx All and use VLAN Table
Configuration for Tx.
Parameter Default Description
GVRP Enabled Enables or disables GVRP for this port. When disabled, any GVRP
packets received on this port will be discarded and no GVRP registrations
will be propagated from other ports.
Note that GVRP must be enabled globally for the switch before this
setting can take effect. (See “4.5.3.1 Configuring Global Bridge Settings”)
GMRP
*4
Enabled Enables or disables GMRP for this port. When enabled, this port will allow
end stations to register with multicast groups using GMRP. Note that
GMRP must be enabled for the switch before this setting can take effect.
IGMP and IGMP Snooping also provide multicast filtering. (See “6.4.2
IGMP Protocol”)
Ingress
Filtering
*5
Disabled If enabled, incoming frames for VLANs which do not include this ingress
port in their member set will be discarded at the ingress port.
4: Only displayed on WGS3-2620.
5: This control does not affect VLAN independent BPDU frames, such as GVRP or STP. However, they
do affect VLAN dependent BPDU frames, such as GMRP.
