WGS3 Layer 3 Switch User’s Manual
- 154 -
5.7 Device Control Menu
The Device Control menu is used to control a broad range of functions, including port mode, port
mirroring, port trunking, Spanning Tree, Virtual LANs, IP subnets, multicast filtering, and routing protocols.
Each of the setup screens provided by these configuration menus is described in the following sections.
Menu Description
Layer 2 Menu Configures port communication mode, mirror ports, port trunking, and static
addresses.
Bridge Menu Configures the Spanning Tree Protocol for the bridge or for specific ports, GMRP
and GVRP for automatic registration of multicast and VLAN groups, traffic class
priority threshold, and address aging time.
VLAN Menu Configures VLAN settings for specific ports, and defines the port membership for
VLAN groups.
IGMP Snooping
Configuration
*1
Configures IGMP multicast filtering.
IP Menu2 Configures the subnets for each VLAN group, global configuration for ARP and
Proxy ARP, unicast and multicast protocols, static ARP table entries, static routes
and the default route.
Security Menu Configures MAC and IP
*2
Address filtering.
1: Only displayed for Layer 2 mode of WGS3-2620.
2: Only displayed for WGS3-404 and multilayer mode of WGS3-2620.
