WGS3 Layer 3 Switch User’s Manual
- 151 -
5.6.3 User Login Configuration
Use the User Configuration screen to restrict management access based on user names and passwords.
The default administrator (admin) has write access for parameters governing the on-board agent. You
should therefore assign a password to the administrator as soon as possible, and store it in a safe place.
5.6.3.1 Displaying the Current User Configuration
Use this menu to display the names and access rights for people authorized to manage the switch.
Parameter Description
User Name* Specifies a user authorized management access to the switch via the console, Telnet
or HTTP. An entry can only be deleted via the console interface.
User Password* Password associated with this entry.
Access Right ADMIN: Read/Write for all screens.
GUEST: Read Only for all screens.
Console Authorizes management via the console.
Telnet Authorizes management via Telnet.
HTTP Authorizes management via HTTP.
*These entries can consist of up to 15 alphanumeric characters and are not case sensitive.
