WGS3 Layer 3 Switch User’s Manual
- 145 -
5.6 Management Setup Menu
After initially logging onto the system, you can use this menu to configure access rights. You should set
user names and passwords (User Configuration). Remember to record them in a safe place. You should
also set the community string which controls access to the on-board SNMP agent via in-band
management software (SNMP Configuration). The items provided by the Management Setup Menu are
described in the following sections.
Menu Description
Network Configuration Includes IP setup * and HTTP setup for the on-board Web agent.
Serial Port
Configuration
Sets communication parameters for the serial port, including baud rate, console
time-out, and screen data refresh interval. (See “Configuring the Serial Port”)
SNMP Configuration Activates authentication failure traps; and configures communities and trap
managers.
User Configuration Sets the user names and passwords for system access.
TFTP Download Downloads new version of firmware to update your system (in-band).
Configuration File Saves or restores configuration data based on the specified file.
* Only displays on WGS3-2620 when it is set to Layer 2 mode.
