WGS3 Layer 3 Switch User’s Manual
- 144 -
5.5.2.2 WGS3-404
Parameter Description
Hardware Version Hardware version of the main board.
Firmware Version System firmware version in ROM.
Serial Number The serial number (MAC address) of the main board.
Port Number Number of ports on this switch.
Packet Memory Size Shows memory size for packet buffer. It is always 6M bytes.
