WGS3 Layer 3 Switch User’s Manual
- 123 -
4.6.6.5.1 Display Interface Table
This function allow you to display each IP interface’s OSPF status.
Parameter Description
IP Address IP address of the interface
Rtr ID The OSPF identifier for the neighboring router.
Designated Rtr The designated router IP address for the broadcast network on the interface
Backup Rtr The backup designated router IP address for the broadcast network on the
interface
Status The interface status.
Events The number of events encountered that cause a neighbor state change since
boot up.
