WGS3 Layer 3 Switch User’s Manual
- 118 -
Parameter Description
Group Address An IP multicast group address with subscribers directly attached or downstream
from this switch.
Intf The IP interface on this switch that has received traffic directed to the IP
multicast group address. (See 4.6.6.1 Displaying Subnet Information.)
Reporter IP address of the source of the last membership report received for this multicast
group on this interface. If no membership report has been received, this object
has the value 0.0.0.0.
Up Time The time elapsed since this entry was created.
Expire The time remaining before this entry will be aged out. (The default is 260
seconds.)
V1 Timer The time remaining until the switch assumes that there are no longer any IGMP
Version 1 members on the IP subnet attached to this interface. (The default is
400 seconds.)
If the switch receives an IGMP Version 1 Membership Report, it sets a timer to
note that there are Version 1 hosts present which are members of the group for
which it heard the report.
If there are Version 1 hosts present for a particular group, the switch will ignore
any Leave Group messages that it receives for that group.
NOTE: To scroll through the table, use the <Next Page> and <Prev Page> buttons. To display a
specific page, set the page number in the Page field and then select <Apply>.
