WGS3 Layer 3 Switch User’s Manual
- 114 -
Parameter Description
Destination
Network
A destination network, subnet or host.
Destination Mask The subnet mask that specifies the bits to match. A routing entry will be used for a
packet if the bits in the address set by the destination mask match the Destination
Network.
VLAN The VLAN within which the gateway or destination address resides.
Next Hop The IP address of the router at the next hop.
Type The IP route type for the destination network. This switch supports the following types:
Direct - A directly connected subnetwork.
Indirect - A remote IP subnetwork or host address.
Myself - A switch IP address on a specific IP subnetwork.
Bcast - A subnetwork broadcast address.
Mcast - An IP multicast address.
Invalid - An illegal IP address to be filtered.
Protocol The route was learned in one of the following ways:
Local - Manually configured
Mgmt - Set via SNMP
ICMP - Obtained via ICMP redirect.
RIP - Learned via RIP protocol.
OSPF – Learned via OSPF protocol.
Other - Learned by some other method.
NOTE: Use the <Next Page> and <Prev Page> buttons to scroll through the routing table. To display a
specific page, set the page number in the Page field and then press <Apply>. Select <Flush
RIP> to clear any routing entries learned through RIP.
