WGS3 Layer 3 Switch User’s Manual
- 94 -
4.6.1 Displaying Port Statistics
Port Statistics display standard statistics on network traffic from the Interfaces Group and Ethernet-like
MIBs, as well as a detailed breakdown of traffic based on the RMOM MIB.
Menu Description
Port Statistics Displays statistics on network traffic passing through the selected port.
RMON Statistics Displays detailed statistical information for the selected port such as packet type
and frame size counters.
