WGS3 Layer 3 Switch User’s Manual
- 2 -
1.2 Specification
HARDWARE SPECIFICATIONS
Product IP Layer 3 10/100/1000Mbps Routing Switch
Model WGS3-2620 WGS3-404
100Base-TX Ports 24
1000Base-T Ports 2 4
Module Slot 4
LED for system Power, SNMP, Console, Fan Power, OverHeat, FanFailure
LED indicators for
100Base-TX
Two per port; Link, Mode (Modes
include FDX, ACT, Speed)
LED indicators for
1000Base-T
LNK, FDX 10, 100, 1000, FDX/COL, ACT
Media Type RJ-45 STP, Auto-MDI/MDI-X on Gigabit port
Cabling 100Mbps: Category 5 UTP, 4-wire
1000Mbps: Category 5/5e or above, 8-wire
Rack Mount 1.U, 19” Rack mount
Dimensions 430 mm x 334 mm x 44 mm (W x D x H)
Weight 4.2kg 4kg
SWITCHING SPECIFICATIONS
Architecture High Performance Store & Forward Switching Architecture
Buffer Memory 4MB 6MB
Switching fabric 8.53Gbps 19.2Gbps
MAC address
Table
Layer 2: 32K MAC-entry
Layer 3:64K IP- entry
Forwarding/filtering
rate
Layer 2 wired speed forwarding
Layer 3 wired speed forwarding
Error Checking Runt & CRC on all network packets
Trunking 10/100 Ports: Up to 8 ports per trunk
Gigabit Ports: 2 gigabit ports as a
trunk
Up to 4 ports per trunk
Port Mirroring Monitor port transmitting / receiving activity
QoS Port based, VLAN tag
Dual priority queues for each port
4 priority queues for each port
Protocol
Compatibility
Layer 2: Transparent to higher layer protocols
Layer 3: IP RIP-1, RIP-2, OSPF DVMRP
Security IP and MAC filtering
Configuration telnet, Web, RS-232 DB-9 console port and SNMP
Network
Management
RFC 1157 SNMP v1/v2
RFC 1213 MIB II
RFC 1493 Bridge MIB
RFC 1643 Ethernet MIB
RFC 1724 RIP v2 MIB
RFC 1757 RMON 4 groups: stats, history, Alarms & Events
Protocols and
Standards
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3z/802.3ab Gigabit Ethernet
