The page includes the following fields:
Object Description
• Port
This is the logical port number for this row.
• Link
The current link state is displayed graphically. Green indicates the link is up and
red that it is down.
• Current Link Speed
Provides the current link speed of the port.
• Configured Link Speed
Select any available link speed for the given switch port. Draw the menu bar to
select the mode.
• Auto Speed - Setup Auto negotiation.
• 10 half - Force sets 10Mbps/Half-Duplex mode.
• 10 Full - Force sets 10Mbps/Full-Duplex mode.
• 100 half - Force sets 100Mbps/Half-Duplex mode.
• 100 full - Force sets 100Mbps/Full-Duplex mode.
• 1000 full - Force sets 10000Mbps/Full-Duplex mode.
• Disable - Shutdown the port manually.
• Flow Control
When Auto Speed is selected for a port, this section indicates the flow control
capability that is advertised to the link partner.
When a fixed-speed setting is selected, that is what is used.
• Current Rx column indicates whether pause frames on the port are
obeyed.
• Current Tx column indicates whether pause frames on the port are
transmitted.
The Rx and Tx settings are determined by the result of the last Auto-Negotiation.
Check the configured column to use flow control.
This setting is related to the setting for Configured Link Speed.
• Maximum Frame
Enter the maximum frame size allowed for the switch port, including FCS. The
allowed range is 1518 bytes to 9600 bytes.
• Excessive Collision
Mode
Configure port transmit collision behavior.
• Discard: Discard frame after 16 collisions (default).
• estart: Restart backoff algorithm after 16 collisions.
• Power Control
The Usage column shows the current percentage of the power consumption per
port. The Configured column allows for changing the power savings mode
parameters per port.
• Disabled: All power savings mechanisms disabled.
• ActiPHY: Link down power savings enabled.
• Dynamic: Link up power savings enabled.
