User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
77
• Authentication
Password
A string identifying the authentication pass phrase. For MD5 authentication
protocol, the allowed string length is 8 to 32. For SHA authentication protocol, the
allowed string length is 8 to 40. The allowed content is the ASCII characters from
33 to 126.
• Privacy Protocol
Indicates the privacy protocol that this entry should belong to. Possible privacy
protocol are:
• None: None privacy protocol.
• DES: An optional flag to indicate that this user using DES authentication
protocol.
• Privacy Password
A string identifying the privacy pass phrase. The allowed string length is 8 to 32,
and the allowed content is the ASCII characters from 33 to 126.
4.3.5.5 SNMPv3 Views Configuration
Configure SNMPv3 views table on this page. The entry index key are View Name and OID Subtree.
The SNMPv3 Views Configuration screen in Figure 4-3-8 appears.
Figure 4-3-8 SNMPv3 Views Configuration page screenshot
The page includes the following fields:
Object Description
• Delete • Check to delete the entry. It will be deleted during the next save.
• View Name
A string identifying the view name that this entry should belong to. The allowed
string length is 1 to 32, and the allowed content is the ASCII characters from 33
to 126.
• View Type
Indicates the view type that this entry should belong to. Possible view type are:
• included: An optional flag to indicate that this view subtree should be
included.
• excluded: An optional flag to indicate that this view subtree should be
excluded.
