User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
75
from 33 to 126.
• Source IP
Indicates the SNMP access source address.
• Source Mask
Indicates the SNMP access source address mask.
4.3.5.3 SNMPv3 Groups Configuration
Configure SNMPv3 groups table on this page. The entry index key are Security Model and Security Name.
The SNMPv3 Groups Configuration screen in Figure 4-3-6 appears.
Figure 4-3-6 SNMPv3 Groups Configuration page screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Security Model
Indicates the security model that this entry should belong to. Possible security
models are:
• v1: Reserved for SNMPv1.
• v2c: Reserved for SNMPv2c.
• usm: User-based Security Model (USM).
• Security Name
A string identifying the security name that this entry should belong to.
The allowed string length is 1 to 32, and the allowed content is the ASCII
characters from 33 to 126.
• Group Name
A string identifying the group name that this entry should belong to.
The allowed string length is 1 to 32, and the allowed content is the ASCII
characters from 33 to 126.
