User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
74
• Security Model
Indicates the security model that this entry should belong to. Possible security
models are:
• any: Accepted any security model (v1|v2c|usm).
• v1: Reserved for SNMPv1.
• v2c: Reserved for SNMPv2c.
• usm: User-based Security Model (USM)
• Security Level
Indicates the security model that this entry should belong to. Possible security
models are:
• NoAuth, NoPriv: None authentication and none privacy.
• Auth, NoPriv: Authentication and none privacy.
• Auth, Priv: Authentication and privacy.
• Read View Name
The name of the MIB view defining the MIB objects for which this request may
request the current values. The allowed string length is 1 to 32, and the allowed
content is the ASCII characters from 33 to 126.
• Write View Name
The name of the MIB view defining the MIB objects for which this request may
potentially SET new values. The allowed string length is 1 to 32, and the allowed
content is the ASCII characters from 33 to 126.
4.3.5.2 SNMPv3 Communities Configuration
Configure SNMPv3 communities table on this page. The entry index key is Community.
The SNMPv3 Communities Configuration screen in Figure 4-3-5 appears.
Figure 4-3-5 SNMPv3 Communities Configuration page screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Community
Indicates the community access string to permit access to SNMPv3 agent. The
allowed string length is 1 to 32, and the allowed content is the ASCII characters
