User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
73
• Trap Probe Security
Engine ID
Indicates the SNMP trap probe security engine ID mode of operation. Possible
values are:
• Enabled: Enable SNMP trap probe security engine ID mode of operation.
• Disabled: Disable SNMP trap probe security engine ID mode of operation.
• Trap Security Engine
ID
Indicates the SNMP trap security engine ID. SNMPv3 sends traps and informs
using USM for authentication and privacy. A unique engine ID for these traps and
informs is needed. When "Trap Probe Security Engine ID" is enabled, the ID will
be probed automatically. Otherwise, the ID specified in this field is used. The
string must contain an even number between 10 and 64 hexadecimal digits, but
all-zeros and all-'F's are not allowed.
• Trap Security Name
Indicates the SNMP trap security name. SNMPv3 traps and informs using USM
for authentication and privacy. A unique security name is needed when traps and
informs are enabled.
4.3.5 SNMPv3 Configuration
4.3.5.1 SNMPv3 Accesses Configuration
Configure SNMPv3 accesses table on this page. The entry index key are Group Name, Security Model and Security Level.
The SNMPv3 Accesses Configuration screen in Figure 4-3-4 appears.
Figure 4-3-4 SNMPv3 Accesses Configuration page screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Group Name
A string identifying the group name that this entry should belong to. The allowed
string length is 1 to 32, and the allowed content is the ASCII characters from 33
to 126.
