Figure 4-2-8 TFTP Firmware upgrade pop-up message
Figure 4-2-9 Firmware Upgrade pop-up message
4. Click “OK”, the Switch will start the TFTP upgrade procedure.
5. Please check your TFTP server application to confirm the TFTP file is well transmit to the Switch.
6. The Switch will reboot then, and It will cost 2 to 3 minutes for the TFTP firmware upgrade and reboot procedure. Please
wait for the process complete.
7. Once the new software is loaded to the system successfully, the Login screen appears. Enter the user name and password
to login the Switch.
DO NOT Power OFF the switch until the update progress is complete.
Do not quit the Firmware Upgrade page without press the “OK” button - after the image be
loaded. Or the system won’t apply the new firmware. User has to repeat the firmware
upgrade processes again.
