1. The stack switch with least priority ID or MAC Address number will become Master. Only Master
switch’s management interface (console, telnet, web and SNMP) is accessible.
2.
It’s allow to build a stack of up to 16 PLANET SGSW Switches. If there is the space limitation or power issue and you wish to
stack all the switches in different racks, use long stack cables “CB-STX200” to connect two stacks.
Figure 2-29 Separated Stack connection
2m stack cable CB-STX200 2m stack cable CB-STX200
CB-STX50
