User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
302
PoE Status
Example:
SWITCH/> poe status
Port Port Status PD Class Power Used [W] Current Used [mA]
---- ------------------- -------- --------------------- --------------------------
1 PoE ON 2 4.8 95
2 PoE OFF 0 0.0 0
3 PoE OFF 0 0.0 0
4 PoE OFF 0 0.0 0
5 PoE OFF 0 0.0 0
6 PoE OFF 0 0.0 0
7 PoE OFF 0 0.0 0
8 PoE OFF 0 0.0 0
9 PoE OFF 0 0.0 0
10 PoE OFF 0 0.0 0
11 PoE OFF 0 0.0 0
12 PoE OFF 0 0.0 0
13 PoE OFF 0 0.0 0
14 PoE OFF 0 0.0 0
15 PoE OFF 0 0.0 0
16 PoE OFF 0 0.0 0
17 PoE OFF 0 0.0 0
18 PoE OFF 0 0.0 0
19 PoE OFF 0 0.0 0
20 PoE OFF 0 0.0 0
21 PoE OFF 0 0.0 0
22 PoE OFF 0 0.0 0
23 PoE OFF 0 0.0 0
24 PoE OFF 0 0.0 0
Total 4.8 95
Current Power Consumption 4.8[W] (2%)
Total Power Reserved 7.268[W] (3%)
Temperature 1 37 (C) / 98 (F)
Temperature 2 43 (C) / 109 (F)
