User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
301
SWITCH/> poe mgmt_mode
Power management mode
-------------------------------------
Power management mode : automode
PoE Maximum_Power
Description:
Set or show PoE maximum power per port (0-15.4, with one digit).
Syntax:
PoE Maximum_Power [<port_list>] [<port_power>]
Parameters:
<port_list> : Port list or 'all', default: All ports
<port_power>: PoE maiximum power for the port ( 0-15.4 )
PoE Alloc_Power
Description:
PoE Alloc_Power [<port_list>] [<alloc_power>].
Syntax:
PoE Mgmt_mode [mgt_class|mgt_alloc|mgt_auto|mgt_consumption|mgt_priority]
Parameters:
<port_list> : Port list or 'all', default: All ports
<alloc_power>: PoE maiximum power allocated for the port ( 0-15.4 )
PoE Power_Supply
Description:
Set or show the value of the power supply.
Syntax:
PoE Power_Supply [<supply_power>]
Parameters:
<supply_power>: PoE power for a power supply
PoE Status
Description:
Show PoE status.
Syntax:
