User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
299
Example:
Assign SID2 for switch that use MAC address 00-30-4f-24-04-76
SWITCH/>stack sid assign 2 00-30-4f-24-04-76
6.13 Power over Ethernet Command
PoE Configuration
Description:
Show PoE configuration.
Syntax:
PoE Configuration
Example:
SWITCH/>poe configuration
Port Mode Priority Max.Power[W] PowerAlloc[W]
---- ------- -------- --------------- -------------
1 Enabled High 15.4 15.4
2 Enabled High 15.4 15.4
3 Enabled High 15.4 15.4
4 Enabled High 15.4 15.4
5 Enabled High 15.4 15.4
6 Enabled High 15.4 15.4
7 Enabled High 15.4 15.4
8 Enabled High 15.4 15.4
9 Enabled High 15.4 15.4
10 Enabled High 15.4 15.4
11 Enabled High 15.4 15.4
12 Enabled High 15.4 15.4
13 Enabled High 15.4 15.4
14 Enabled High 15.4 15.4
15 Enabled High 15.4 15.4
16 Enabled High 15.4 15.4
17 Enabled High 15.4 15.4
18 Enabled High 15.4 15.4
19 Enabled High 15.4 15.4
20 Enabled High 15.4 15.4
21 Enabled High 15.4 15.4
22 Enabled High 15.4 15.4
23 Enabled High 15.4 15.4
24 Enabled High 15.4 15.4
Power Supply Max.
-------------------
220 [W]
Power management mode
----------------------
Power management mode : automode
