User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
252
dot1q : Set out layer VLAN tag ether type : 802.1Q
Default Setting:
N/A
Example:
SWITCH/>vlan ethtype 10 man
VLAN Add
Description:
Add or modify VLAN entry.
Syntax:
VLAN Add <vid> [<port_list>]
Parameters:
<vid> : VLAN ID (1-4095)
<port_list>: Port list or 'all', default: All ports
Default Setting:
1
Example:
Add port17 to port24 in VLAN10
SWITCH/>vlan add 10 17-24
VLAN Delete
Description:
Delete VLAN entry.
Syntax:
VLAN Delete <vid>
Parameters:
