User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
21
SGSW Stackable PoE models
Product SGSW-24040P SGSW-24040P4
Hardware Specification
Copper Ports
24 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
SFP/mini-GBIC Slots
4 SFP interfaces, shared with Port-21 to Port-24
Stacking Ports
2 5GbE / Cross-HDMI interface
Switch Fabric
68Gbps
Address Table
8K entries
Share data Buffer
1392 kilobytes
Switch Processing Scheme
Store-and-Forward
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame
10Kbytes
LED
Power, Stack Master, Stack Port LNK, Link/Act and speed per Gigabit port
Power Consumption
Max. 290 watts / 989 BTU
Max. 430.2 watts / 1467 BTU
Power Requirement – AC
AC 100~240V, 50/60Hz AC 100~240V, 50/60Hz
Power Requirement – DC
---- ---
Stacking Numbers
16
Stacking Bandwidth
10Gbps Full-Duplex
Stack ID Display
7-Segment LED Display (1~9, A~F,0)
Power over Ethernet
PoE Standard
IEEE 802.3af Power over Ethernet / PSE
PoE Power Supply Type
End-Span
PoE Power Output
Per Port 48V DC, 350mA . Max. 15.4 watts
Power Pin Assignment
1/2(+), 3/6(-)
PoE Power Budget
220 Watts 380 Watts
Number of PD @
7Watts
24 24
PoE Ability
Number of PD @
15.4Watts
14 24
