User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
207
Figure 4-16-9 Stack Information page screenshot - Master Forwarding Table
4.16.4 Stack Port State Ovewview
This page provides an overview of the current switch port states. Clicking on the image of a port opens the Port Statistics
page.The port states are illustrated as follows:
Figure 4-16-10 Port State Overview page screenshot
MASTER LED
SWITCH ID
Port Link status
Stack Port Link status
