User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
19
■ Mirror across stack
■ Link Aggregation groups spanning multiple switches in a stack
■ Hardware learning with MAC table synchronization across stack
¾ Redundant Power System (WGSW-24040R / SGSW-24040R)
■ 100~240V AC / 48V DC Dual power redundant
■ Active-active redundant power failure protection
■ Backup of catastrophic power failure on one supply
■ Fault tolerance and resilience.
¾ Power over Ethernet (SGSW-24040P / SGSW-24040P4 Only)
■ Complies with IEEE 802.3af Power over Ethernet End-Span PSE
■ Up to 24 IEEE 802.3af devices powered
■ Support PoE Power up to 15.4 watts for each PoE ports
■ Auto detect powered device (PD)
■ Circuit protection prevent power interference between ports
■ Remote power feeding up to 100m
■ PoE Management
■ Total PoE power budget control
■ Pert port PoE function enable/disable
■ PoE Port Power feeding priority
■ Per PoE port power limit
■ PD classification detection
1.5 Product Specification
WGSW Standalone models
Product WGSW-24040 WGSW-24040R
Hardware Specification
Copper Ports
24 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
SFP/mini-GBIC Slots
4 SFP interfaces, shared with Port-21 to Port-24
Stacking Ports
---
Switch Fabric
48Gbps / non-blocking
Address Table
8K entries
Share data Buffer
1392 kilobytes
Switch Processing Scheme
Store-and-Forward
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
