User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
18
− Private VLAN Edge (PVE)
■ Support Spanning Tree Protocol
− STP, IEEE 802.1d (Spanning Tree Protocol)
− RSTP, IEEE 802.1w (Rapid Spanning Tree Protocol)
■ Support Link Aggregation
− 802.3ad Link Aggregation Control Protocol (LACP)
− Cisco ether-channel (Static Trunk)
− Maximum 12 trunk groups, up to 16 ports per trunk group
− Up to 16Gbps bandwidth(Duplex Mode)
■ Provide Port Mirror (many-to-1)
■ Port Mirroring to monitor the incoming or outgoing traffic on a particular port
¾ Quality of Service
■ 4 priority queues on all switch ports.
■ Supports for strict priority and weighted round robin (WRR) CoS policies
■ Ingress Shaper and Egress Rate Limit per port bandwidth control
■ Traffic-policing policies on the switch port
¾ Multicast
■ Supports IGMP Snooping v1, v2 and v3
■ Querier mode support
¾ Security
■ IEEE 802.1x Port-Based / MAC-Based network access authentication
■ IP-Based Access Control List (ACL)
■ MAC-Based Access Control List
¾ Management
■ WEB-based, Telnet, Console Command Line management
■ Accesses through SNMPv1, v2c and v3 security set and get requests.
■ Built-in Trivial File Transfer Protocol (TFTP) client
■ BOOTP and DHCP for IP address assignment
■ Firmware upload/download via HTTP / TFTP
■ SNTP (Simple Network Time Protocol)
■ LLDP Protocol
¾ Stacking
■ Hardware stack up to 16 units and 384 ports
■ Stacking architecture supports Chain and Ring mode
