User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
170
hits this ACE matches this TCP/UDP source value.
• TCP/UDP Source
Range
When "Range" is selected for the TCP/UDP source filter, you can enter a specific
TCP/UDP source range value. The allowed range is 0 to 65535. A frame that hits
this ACE matches this TCP/UDP source value.
• TCP/UDP Destination
Filter
Specify the TCP/UDP destination filter for this ACE.
• Any: No TCP/UDP destination filter is specified (TCP/UDP destination filter
status is "don't-care").
• Specific: If you want to filter a specific TCP/UDP destination filter with this
ACE, you can enter a specific TCP/UDP destination value. A field for entering
a TCP/UDP destination value appears.
• Range: If you want to filter a specific range TCP/UDP destination filter with this
ACE, you can enter a specific TCP/UDP destination range value. A field for
entering a TCP/UDP destination value appears.
• TCP/UDP Destination
Number
When "Specific" is selected for the TCP/UDP destination filter, you can enter a
specific TCP/UDP destination value. The allowed range is 0 to 65535. A frame
that hits this ACE matches this TCP/UDP destination value.
• TCP/UDP Destination
Range
When "Range" is selected for the TCP/UDP destination filter, you can enter a
specific TCP/UDP destination range value. The allowed range is 0 to 65535. A
frame that hits this ACE matches this TCP/UDP destination value.
• TCP FIN
Specify the TCP "No more data from sender" (FIN) value for this ACE.
• 0: TCP frames where the FIN field is set must not be able to match this entry.
• 1: TCP frames where the FIN field is set must be able to match this entry.
• Any: Any value is allowed ("don't-care").
• TCP SYN
Specify the TCP "Synchronize sequence numbers" (SYN) value for this ACE.
• 0: TCP frames where the SYN field is set must not be able to match this entry.
• 1: TCP frames where the SYN field is set must be able to match this entry.
• Any: Any value is allowed ("don't-care").
• TCP PSH
Specify the TCP "Push Function" (PSH) value for this ACE.
• 0: TCP frames where the PSH field is set must not be able to match this entry.
• 1: TCP frames where the PSH field is set must be able to match this entry.
• Any: Any value is allowed ("don't-care").
• TCP ACK
Specify the TCP "Acknowledgment field significant" (ACK) value for this ACE.
• 0: TCP frames where the ACK field is set must not be able to match this entry.
• 1: TCP frames where the ACK field is set must be able to match this entry.
• Any: Any value is allowed ("don't-care").
• TCP URG
Specify the TCP "Urgent Pointer field significant" (URG) value for this ACE.
• 0: TCP frames where the URG field is set must not be able to match this entry.
• 1: TCP frames where the URG field is set must be able to match this entry.
• Any: Any value is allowed ("don't-care").
