User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
169
address and destination IP mask in the DIP Address and DIP Mask fields that
appear.
• DIP Address
When "Host" or "Network" is selected for the destination IP filter, you can enter a
specific DIP address in dotted decimal notation.
• DIP Mask
When "Network" is selected for the destination IP filter, you can enter a specific
DIP mask in dotted decimal notation.
ICMP Parameters
Object Description
• ICMP Type Filter
Specify the ICMP filter for this ACE.
• Any: No ICMP filter is specified (ICMP filter status is "don't-care").
• Specific: If you want to filter a specific ICMP filter with this ACE, you can
enter a specific ICMP value. A field for entering an ICMP value appears.
• ICMP Type Value
When "Specific" is selected for the ICMP filter, you can enter a specific ICMP
value. The allowed range is 0 to 255. A frame that hits this ACE matches this
ICMP value.
• ICMP Code Filter
Specify the ICMP code filter for this ACE.
• Any: No ICMP code filter is specified (ICMP code filter status is "don't-care").
• Specific: If you want to filter a specific ICMP code filter with this ACE, you
can enter a specific ICMP code value. A field for entering an ICMP code value
appears.
• ICMP Code Value
When "Specific" is selected for the ICMP code filter, you can enter a specific
ICMP code value. The allowed range is 0 to 255. A frame that hits this ACE
matches this ICMP code value.
TCP/UDP Parameters
Object Description
• TCP/UDP Source Filter
Specify the TCP/UDP source filter for this ACE.
• Any: No TCP/UDP source filter is specified (TCP/UDP source filter status is
"don't-care").
• Specific: If you want to filter a specific TCP/UDP source filter with this ACE,
you can enter a specific TCP/UDP source value. A field for entering a
TCP/UDP source value appears.
• Range: If you want to filter a specific TCP/UDP source range filter with this
ACE, you can enter a specific TCP/UDP source range value. A field for
entering a TCP/UDP source value appears.
• TCP/UDP Source No.
When "Specific" is selected for the TCP/UDP source filter, you can enter a
specific TCP/UDP source value. The allowed range is 0 to 65535. A frame that
