User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
167
address field (THA) settings.
0: RARP frames where THA is not equal to the SMAC address.
1: RARP frames where THA is equal to the SMAC address.
Any: Any value is allowed ("don't-care").
• IP/Ethernet Length
Specify whether frames can hit the action according to their ARP/RARP
hardware address length (HLN) and protocol address length (PLN) settings.
0: ARP/RARP frames where the HLN is equal to Ethernet (0x06) and the (PLN)
is equal to IPv4 (0x04) must not match this entry.
1: ARP/RARP frames where the HLN is equal to Ethernet (0x06) and the (PLN)
is equal to IPv4 (0x04) must match this entry.
Any: Any value is allowed ("don't-care").
• IP
Specify whether frames can hit the action according to their ARP/RARP
hardware address space (HRD) settings.
0: ARP/RARP frames where the HLD is equal to Ethernet (1) must not match
this entry.
1: ARP/RARP frames where the HLD is equal to Ethernet (1) must match this
entry.
Any: Any value is allowed ("don't-care").
• Ethernet
Specify whether frames can hit the action according to their ARP/RARP protocol
address space (PRO) settings.
0: ARP/RARP frames where the PRO is equal to IP (0x800) must not match
this entry.
1: ARP/RARP frames where the PRO is equal to IP (0x800) must match this
entry.
Any: Any value is allowed ("don't-care").
IP Parameters
The IP parameters can be configured when Frame Type "IPv4" is selected.
Object Description
• IP Protocol Filter
Specify the IP protocol filter for this ACE.
• Any: No IP protocol filter is specified ("don't-care").
• Specific: If you want to filter a specific IP protocol filter with this ACE, choose
this value. A field for entering an IP protocol filter appears.
• ICMP: Select ICMP to filter IPv4 ICMP protocol frames. Extra fields for
defining ICMP parameters will appear. These fields are explained later in this
help file.
• UDP: Select UDP to filter IPv4 UDP protocol frames. Extra fields for defining
UDP parameters will appear. These fields are explained later in this help file.
• TCP: Select TCP to filter IPv4 TCP protocol frames. Extra fields for defining
