User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
154
The selected port belongs to the currently selected stack unit as reflected by the table header.
EAPOL Counters
These counters are not available for MAC-based ports.
Supplicant frame counter statistics. There are seven receive frame counters and three transmit frame counters.
EAPOL Counters
Direction Name IEEE Name Description
Rx Total dot1xAuthEapolFramesRx
The number of valid EAPOL frames of any type that have
been received by the switch.
Rx Response ID dot1xAuthEapolRespIdFramesRx
The number of valid EAP Resp/ID frames that have been
received by the switch.
Rx Responses dot1xAuthEapolRespFramesRx
The number of valid EAPOL response frames (other than
Resp/ID frames) that have been received by the switch.
Rx Start dot1xAuthEapolStartFramesRx
The number of EAPOL Start frames that have been received
by the switch.
Rx Logoff dot1xAuthEapolLogoffFramesRx
The number of valid EAPOL logoff frames that have been
received by the switch.
Rx Invalid Type dot1xAuthInvalidEapolFramesRx
The number of EAPOL frames that have been received by
the switch in which the frame type is not recognized.
Rx Invalid Length dot1xAuthEapLengthErrorFramesRx
The number of EAPOL frames that have been received by
the switch in which the Packet Body Length field is invalid.
Tx Total dot1xAuthEapolFramesTx
The number of EAPOL frames of any type that have been
transmitted by the switch.
Tx Request ID dot1xAuthEapolReqIdFramesTx
The number of EAP initial request frames that have been
transmitted by the switch.
Tx Requests dot1xAuthEapolReqFramesTx
The number of valid EAP Request frames (other than initial
request frames) that have been transmitted by the switch.
