User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
15
Flexibility and Extension solution
The 4 mini-GBIC slots are compatible with 1000Base-SX/LX and WDM SFP(Small Factor Pluggable) fiber-optic modules. The
distance can be extended from 550 meters (Multi-Mode fiber) up to above 10/50/70/120 kilometers (Single-Mode fiber or
WDM fiber). They are well suited for using within the enterprise data centers and distributions.
Reliability Stacking Management
The SGSW Series Managed Switch provides a switch stacking function to manage up to 16 switches using a single IP
address. That helps network managers to easily configure switches via one single IP address instead of connecting and
setting each unit one by one. Through its high bandwidth tunnel and stacking technology,
it gives enterprise, service
provider and telcom flexible control over port density, uplinks and switch stack performance.
Up to 384 Gigabit
Ethernet ports can be managed by a stacking group and
you can add ports and functionality as needed. The stacking
technology also enables the advantages of chassis-based switches to be integrated into SGSW Series Managed
Switch, but without the expensive up-front cost.
AC / DC Power Redundant to ensure continuous operation
The R series Managed Switch equip with one 100~240V AC power supply unit and one DC -48V power supply unit on its
standard package, it provides redundant power supply installation. A redundant power system is also provided to enhance the
reliability with either 100~240V AC power supply unit or DC -48V power supply unit. The continuous power systems are
specifically designed to handle the demands of high tech facilities requiring the highest power integrity available.
Advanced Features and Centralized Power Management for Enterprise and Campus PoE Networking (PoE Model)
The PLANET SGSW-24040P series PoE Switch provides 24 10/100/1000Mbps Power-over-Ethernet (PoE, IEEE 802.3af
compliant) ports which optimize the installation and power management of network devices such as wireless access points
(AP), Voice over IP (VoIP) phones, and security video cameras. The PoE capabilities also help to reduce deployment costs for
network devices like the wireless AP as a result of freeing from restrictions of power outlet locations. Power and data
switching are integrated into one unit and delivered over a single cable. It thus eliminates cost for additional AC wiring and
reduces installation time.
The below table lists the major hardware diference between the series model:
Model
WGSW-24040 WGSW-24040R SGSW-24040 SGSW-24040R SGSW-24240 SGSW-24240R
SGSW-24040P
SGSW-24040P4
10/100/1000 T 24 24 24 24 8 8 24
Interface
1000SX/LX
4 4 4 4
24, 100FX
compatible
24, 100FX
compatible
4
Redundant Power
-
-48V DC
(-30V~-60V)
-
-48V DC
(-30V~-60V)
-
-48V DC
(-30V~-60V)
-
Power over Ethernet
-
-
-
-
-
- IEEE 802.3af
PoE Budget
-
-
-
-
-
- 220W / 380W
Stack Capability
- - Hardware stacking, up to 16 units
