User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
131
4.8.4.4 Set up VLAN Tag Priority Mapping
Set up the traffic class mapping to the User Priority value (3 bits) when receiving VLAN tagged packets.
The screen in Figure 4-8-11 appears.
Figure 4-8-11 Set up VLAN Tag Priority Mapping page screenshot
The page includes the folling fileds:
Object Description
• QCL ID
Select the QCL ID to which this QCE applies.
• VLAN Priority Class
Select a traffic class of Low, Normal, Medium, or High to apply to the QCE.
The QCL configuration wizard is finished, and the new configuration is ready for use.
