User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
118
Port Type Link Type IEEE 802.1w-2001
Ethernet
Half Duplex
Full Duplex
Trunk
2,000,000
1,000,000
500,000
Fast Ethernet
Half Duplex
Full Duplex
Trunk
200,000
100,000
50,000
Gigabit Ethernet
Full Duplex
Trunk
10,000
5,000
Table 4-7-3 Default STP Path Costs
