User’s Manual of WGSW-24040 Series
SGSW-24040/24240 Series
107
The port settings relate to the currently selected stack unit, as reflected by the page header. This feature works across the stack.
Figure 4-6-4 Private VLAN Configuration page screenshot
The page includes the following fields:
Object Description
• Port
The switch interface.
Displays private VLAN port types.
Isolated
A single stand-alone VLAN that contains one promiscuous
port and one or more isolated (or host) ports. This VLAN
conveys traffic between the isolated ports and a lone
promiscuous port.
• PVLAN Port Type
- Promiscuous
A promiscuous port can communicate with all the interfaces
within a private VLAN.
This is the default setting.
