USB VoIP Gateway SKD-200 User’s Manual 1
Copyright Copyright (C) 2005 PLANET Technology Corp. All rights reserved. The products and programs described in this User’s Manual are licensed products of PLANET Technology, This User’s Manual contains proprietary information protected by copyright, and this User’s Manual and all accompanying hardware, software, and documentation are copyrighted.
Part No. EM-SKD200V1 Index Chapter 1 Introduction.................................................................................................................... 4 SKD-200 Features ............................................................................................................ 4 DECT Features................................................................................................................. 4 Package contents .....................................................................
Chapter 1 Introduction Thank you for choosing SKD-200 USB VoIP Gateway, this product can be used as like as normal PSTN phone plus Skype phone feature. It bundles with a DECT handset to register to SKD-200 for making Skype/ PSTN anywhere. SKD-200 can support computer / laptop to make Skype VoIP calls around the world; also make SkypeOut call for lower phone billed.
• Hands-Free, Mute function • Call duration time meter • Transmitted distance: up to 50~200m indoor / up to 300m outdoor Package contents SKD-200 Base x 1 Adaptor for SKD-200, 5V DC x 1 DECT handset x 1 Charger for DECT handset x 1 Adaptor for DECT handset, 9V DC x 1 USB cable x 1 Telephone line (RJ-11) x 1 AAA Rechargeable batteries x 3 Belt clip x 1 Quick Guide Installation CD-ROM System requirements Minimum System Requirements： Microsoft Windows 2000/ XP/2003 server 400MHz CPU 128MB RAM 15MB free
Chapter 2 SKD-200 Setup 2.
Port Connection Port Descriptions Line For connecting to PSTN line Phone For connecting to a phone set USB For connecting to a computer or laptop DC5V Adapter 5V in (For enhance the power when USB hub is used) DECT Introduction Overview of DECT handset DCT-100 7
Descriptions Intercom conversation mode INT Adjust the volume level during the conversation and menu selection on the LCD display Last Number Redial Hang on / up telephone or pressing until to enable the speaker. C Cancel and Clear R Power on / off Number 0 –9 and # The function is as the same as the general phone set ＊＃ Enter Skype mode DECT Handset Installation The three rechargeable Ni-MH batteries (AAA size) come with your phone. Install the batteries before using your phone. 1.
Reversing the orientation may damage the handset. The battery needs to be replaced if it does not recover ÍNote its full storage capacity after recharging. When replacing batteries, always use good quality Ni-MH re-chargeable AAA size batteries. Never use other batteries or conventional alkaline batteries. Using Headset (optional) The headset jack is located in the middle right side of the handset and is 2.5mm standard plug. Simply plug the headset into the jack and the headset will be activated.
Before initial operation, YOU SHOULD FULLY CHARGE THE HANDSET for 24 hours. To charge the handset, just place it on the charger. When charging, the handset is automatically turned on and the battery icon on the display will blink. 2.2 DECT Screen Display This area displays in-use information such as the caller's number, menus, call duration, etc. In standby mode, the display will show the signal strength icon, battery status icon, handset and base number.
2.
Step5: Finish setup and Run SKS-200 utility Step6: Fist time to run SKD-200, the Skype will show the message, please choose Allow this program to use Skype 12
Step7: The SKD-200 utility will check whether the status (Skype and Hardware) is ok or not. Note: Make sure the SKD-200 device is connected and Skype is online on this computer or notebook.
Step9: In Sound Devices please make sure: Audio In USB device Audio out USB device Ringing 14 USB device
Chapter 3 DCT-100 handset operation 3.1 Icon Status The Hardware and Skype are running properly. The Hardware or Skype are not ready. 3.2 Basic Function Turn Handset On/Off 1. To turn the handset on when the display is off, press and hold the R button. 2. To turn the handset off, press and hold the R button until "Good-Bye" displays. Then the display will turn off. Download Skype contact list or phone 1. Pick up the handset and press the 2. Dial ＊＃ to enter skype mode book to DECT 3.
( with smart country code ) 00886 (Taiwan’s country code is 886) 2. Pick up the handset and press the button. 3. Dial ＊area code + telephone number＃ 4. To end the call, either press the button or replace the handset on the charger. Make a PSTN Call 1. Pick up the handset and press the button. 2. Dial a PSTN phone number. 3. To end the call, either press the button or replace the handset on the charger. Receiving a Call to answer it. 1. When a call is coming, press button 2.
desired handset number. (in this sample, we press the 2 to transfer the call to HS2) 2. The desired handset 2 (HS2) will ring; press the button to answer the call. 3. At this moment, press the button on handset 1 (HS1), the voice call is now transferred to the handset 2 (HS2). 4. If the handset 2 not answer the call, and you’d like to cancel the transfer. On handset 1 (HS1), press the INT button, the call will be re-connected handset 1 (HS1) again. Conference Call 1.
Appendix A Product Specification DCT-100 DECT handset specifications Frequency 1880 ~ 1895 MHz Channel 10 Channel Bandwidth 1.728Mhz Modulate Mode GFSK Output power 10mW, average output per channel Data transfer 1.
