Advanced Settings Menu
56 Planar UltraRes Series User Manual
Tiling Submenu
This menu contains controls for using multiple UltraRes displays in a tiled
configuration. This is useful when trying to display one image across multiple
displays. In addition to setting up the width and height of the tiled wall, each display
must have its position within the tiled wall properly selected. Refer to the diagrams
below for example setting values in a 3 x 4 tiled wall.
Note: When using the Content Rotation feature, the Tiling settings must be adjusted
differently in order to display the image properly. Refer to the examples below.
Example 1: 0 Degree Rotation, Wall Width = 3, Wall Height = 4
Unit Row 1
Unit Column 1
Unit Row 1
Unit Column 2
Unit Row 1
Unit Column 3
Unit Row 2
Unit Column 1
Unit Row 2
Unit Column 2
Unit Row 2
Unit Column 3
Unit Row 3
Unit Column 1
Unit Row 3
Unit Column 2
Unit Row 3
Unit Column 3
Unit Row 4
Unit Column 1
Unit Row 4
Unit Column 2
Unit Row 4
Unit Column 3
