Presets Menu
44 Planar UltraRes Series User Manual
Presets Menu
This menu enables you to save Inputs and Views settings, Image Adjust settings,
Audio settings, the Backlight Intensity setting, the Local Dimming setting, and Tiling
settings. You can save up to 10 presets using this menu (more can be saved via the
serial command interface). If a preset is saved, it will appear as “Preset 1”, “Preset 2”,
and so on. If it is not saved, it will appear as “<Empty>”.
Recall
Apply the setup from the selected preset
Range: Preset 1~Preset 10
Save
Save the current setup for later recall
Range: Preset 1~Preset 10
Delete
Delete the selected preset
Range: Preset 1~Preset 10
