Signal Compatibility
Planar UltraRes Series User Manual 81
HDTV 1080i 50 28.12574.500xxxSMPTE 274M, CEA-861-F Format 20
1080i 60 33.75074.250xxxSMPTE 274M, CEA-861-F Format 5
720p 50 37.50074.250xxxSMPTE 296M, CEA-861-F Format 19
720p 60 45.00074.250xxxSMPTE 296M, CEA-861-F Format 4
1080p 24 27.00074.250xxxSMPTE 274M, CEA-861-F Format 32
1080p 25 28.12574.250xxxSMPTE 274M, CEA-861-F Format 33
1080p 30 33.75074.250xxxSMPTE 274M, CEA-861-F Format 34
1080p 50 56.250148.500xxxSMPTE 274M, CEA-861-F Format 31
1080p 60 67.500148.500xxxSMPTE 274M, CEA-861-F Format 16
UHDTV3840x216024 54.000297.000xxxCEA-861-F Format 93, HDMI 1.4b VIC 1
3840x216025 56.250297.000xxxCEA-861-F Format 94, HDMI 1.4b VIC 2
3840x216030 67.500297.000xxxCEA-861-F Format 95, HDMI 1.4b VIC 3
3840x2160 50 67.500 297.000 x CEA-861-F Format 96, 4:2:0 sub-
sampling
3840x2160 50 135.000 594.000 x x CEA-861-F Format 96
3840x2160 60 67.500 297.000 x CEA-861-F Format 97, 4:2:0 sub-
sampling
3840x2160 60 135.000 594.000 x x CEA-861-F Format 97
Signal
Type
Resolution
Frame rate
(Hz)
Line Rate
(kHz)
Pixel Rate
(MHz)
HDMI 1-2, OPS
HDMI 3-4
DisplayPort
References
