Manual

Advanced Settings Menu
60 Planar UltraRes Series User Manual
Tiling Enabled
When enabled, the tiling parameters in the menu are used
Options: Disable, Enable; Default: Disable
Wall Width,
Wall Height
Select the width and height of the tiled wall
Default: Width=1, Height=1
Unit Column,
Unit Row
Selects the location of the current display within the tiled wall
Default: Column=1, Row=1
Frame Compensation
When enabled, the image is scaled to compensate for the width of the display’s bezel,
using the Frame Width and Frame Height parameters. See "Frame Compensation
Examples" on page 61.
Options: Disable, Enable; Default: Disable
Frame Width,
Frame Height
Selects how many lines/pixels are removed from the image to compensate for the
display’s bezel
