Advanced Settings Menu
54 Planar UltraRes Series User Manual
Current Zone
The zone that is currently being adjusted. All of the settings in this menu are saved per
zone, and all color coordinate values are also saved per Color Gamut setting. The zone’s
corresponding input source is shown in the title bar, and the graphic beneath that shows
which zone is being adjusted in the current Multi-Source View mode and Advanced
Layout setting (if applicable).
The current zone can be changed via the menu or by using the ZONE 1-4 keys on the
remote control.
Note: Changing the Current Zone setting via the ZONE 1-4 keys also changes the Audio
Select setting.
White x
Adjust the x coordinate of the white color point
Range: 0.000-0.800
White y
Adjust the y coordinate of the white color point
Range: 0.000-0.800
Red x
Adjust the x coordinate of the red color point
Range: 0.000-0.800
Red y
Adjust the y coordinate of the red color point
Range: 0.000-0.800
Green x
Adjust the x coordinate of the green color point
Range: 0.000-0.800
Green y
Adjust the y coordinate of the green color point
Range: 0.000-0.800
Blue x
Adjust the x coordinate of the blue color point
Range: 0.000-0.800
Blue y
Adjust the y coordinate of the blue color point
Range: 0.000-0.800
