Planar UltraRes User Manual 89
Accessing Planar’s
Technical Support
Website
1 Go to www.planarpartners.com
2 Once you enter your login and password, you can access downloadable utility software,
new firmware, user manuals, and service manuals.
Downloading Additional Documentation and Firmware
Some of the other documents for the UltraRes 4K professional display, which are or will
be available on www.planar.com.
Downloading Utility Software
1 Go to www.planarpartners.com.
2 Enter your login and password information.
3 Navigate to the section that contains software updates and then look for Planar UltraRes.
4 From the list of available software, click on the tool you need.
