Signal Compatibility
Planar UltraRes User Manual 83
Signal Compatibility
The UltraRes display supports the following video modes.
Compatible Video Sources
Signal Type Resolution Frame Rate (Hz) Line Rate (kHz) Pixel Rate (MHz)
PC 960 x 2160 60 135.000 148.500
HDTV 1080p 24 27.000 74.250
1080p 25 28.125 74.250
1080p
30 33.750 74.250
1080p
50 56.250 148.500
1080p
60 67.500 148.500
UHDTV 3840 x 2160 24 54.000 297.000
3840 x 2160 25 56.250 297.000
3840 x 2160 30 67.500 297.000
Multiple Input Compatibility
Signal Type Resolution Frame Rate (Hz)
PC 960 x 2160 60
✓✓
HDTV 1080p 24
✓✓ ✓
1080p 25
✓✓ ✓ ✓
1080p 30
✓✓ ✓ ✓
1080p 50
✓✓ ✓ ✓
1080p 60
✓✓ ✓ ✓
UHDTV 3840 x 2160 24
✓✓
3840 x 2160 25
✓✓
3840 x 2160 30
✓✓
HDMI -1 Input
HDMI -1-4
DisplayPort -1
Input
DisplayPort 1-4
