Planar UltraRes User Manual 81
Specifications
LCD Module Specifications
Specification UltraRes Display
Dimensions in/lbs mm/kg
Width
75.5” 1918.7mm
Height 43.7” 1110.7mm
Diagonal overall 87.28” 2217mm
Depth - without mount 3.05” 77.5mm
Depth - with mount
3.17” 80.5mm
Weight
LCD only 180lbs 82kg
Landscape mounts 32lbs 14.5kg
Portrait mounts
20lbs 9kg
Orientation Landscape (3D, LX, MX) or Portrait (MX version only)
Rear clearance required None if using Planar’s mount system
Aspect ratio 16:9 (landscape)
9:16 (portrait
LED life 30,000 (half brightness)
LCD Optical Specifications
Specification Maximum Minimum Typical
Screen brightness
UR8450-3D
UR8450-LX
UR8450-MX
336 cd/m
2
280 cd/m
2
400 cd/m
2
420 cd/m
2
350 cd/m
2
500 cd/m
2
Sequential contrast (local dimming enabled)
UR8450-3D
UR8450-LX
UR8450-MX
20,000:1
20,000:1
20,000:1
Sequential contrast (local dimming disabled)
UR8450-3D
UR8450-LX
UR8450-MX
1100:1
1100:1
1100:1
1600:1
1600:1
1400:1
Uniformity 70%
Viewing Angle
2D content
3D content
89° in all directions
10° in all directions
