Planar UltraRes Remote Monitoring Software
Planar UltraRes User Manual 61
Planar UltraRes Remote Monitoring Software
Planar UltraRes Remote Monitoring is software that displays information about the
display via a web browser. It is used primarily for monitoring, reporting and some
control (for example, manually powering the displays on and off).
Remote Monitoring Home
This is the first page you will see when you open the Planar UltraRes Remote
Monitoring software.
