user manual
Table Of Contents
- Table of Contents
- Introduction
- Installing a Planar UltraRes Display
- LCD Installation
- Installing the UltraRes Control Software
- Using the UltraRes Control Software
- UltraRes Dimensions
- Display Dimensions - Front and Side Views
- Display Dimensions - Rear View
- Landscape Wall Mounts - Front View
- Landscape Wall Mounts - Sides Views
- Portrait Wall Mounts - Front View
- Portrait Wall Mounts - Sides Views
- Optional Pedestal Mount - Front View
- Optional Pedestal Mount - Top and Bottom Views
- Optional Pedestal Mount - Single and Double Sided
- Planar UltraRes Remote Monitoring Software
- RS232 Communication
- RS232 Commands
- Command Format
- Response Format
- Supported UltraRes 4K Commands
- Specifications
- Troubleshooting During Installation
- Accessing Planar’s Technical Support Website
- Regulatory Information
- Index
Unpacking and Checking Accessories
Planar UltraRes User Manual 19
Accessory Kit
The following items are included in the accessory kit.
Part Description
Number
Included
AC power cord Power cord. 1
IR sensor Used to receive signals from
the remote control.
1
Double-sided
tape
Used to help in mounting
the IR sensor module.
2
USB drive Contains the User Manual
and setup software.
1
Passive USB
cable
Used to set up display
software.
1
Remote control Used to power the display
on/off, select multiple or
single inputs.
Note: Batteries are included
but not installed.
1
