user manual
Table Of Contents
- Table of Contents
- Introduction
- Installing a Planar UltraRes Display
- LCD Installation
- Installing the UltraRes Control Software
- Using the UltraRes Control Software
- UltraRes Dimensions
- Display Dimensions - Front and Side Views
- Display Dimensions - Rear View
- Landscape Wall Mounts - Front View
- Landscape Wall Mounts - Sides Views
- Portrait Wall Mounts - Front View
- Portrait Wall Mounts - Sides Views
- Optional Pedestal Mount - Front View
- Optional Pedestal Mount - Top and Bottom Views
- Optional Pedestal Mount - Single and Double Sided
- Planar UltraRes Remote Monitoring Software
- RS232 Communication
- RS232 Commands
- Command Format
- Response Format
- Supported UltraRes 4K Commands
- Specifications
- Troubleshooting During Installation
- Accessing Planar’s Technical Support Website
- Regulatory Information
- Index
Unpacking and Checking Accessories
Planar UltraRes User Manual 17
Unpacking and Checking Accessories
LCD Module Box
The following items are included in the LCD module box.
Part Description Number Picture
LCD module One per box. 1
LCD mounts
(optional)
If ordered, this will be inside a
separate box inside the LCD
box.
Note: If you do not use
Planar’s mounts, you need to
ensure the mounts that you
purchase can adequately
support the display.
1
Mounting
template
Used to line up where the
wall mounts will be installed.
This is included with Planar’s
optional LCD mounts.
1
