Planar UltraRes User Manual 11
Installing a Planar
UltraRes Display
This section explains how to install a Planar UltraRes display. We suggest that you
read this entire section before you attempt to install a display.
Before You Begin
Make sure you have all the items in the following lists before you begin unpacking
and installing your display.
Tools/Equipment List
Depending on your installation, you may need one or more of the following items:
• #1 and # 2 Phillips screwdriver
• Drill and bits
•Pencil
• Digital/laser level
• Ladders/lift
• Back brace
• Stud finder (if hanging on a wall)
Other Things You May Need
• LCD screen cleaner or LCD wipes - available at most electronics stores
• At least two capable people to lift display into place
Plan Your Installation
You should have a detailed plan of how the Planar UltraRes display is to be
configured. The plan should include calculations for the following:
• Floor/wall load. Make sure the floor/wall is strong enough to support the
weight of the Planar UltraRes.
• For passive cooling, it is recommended that a minimum of 1” of top clearance is
provided. This can be reduced if the LCD is actively cooled.
• Ventilation and cooling requirements. Although the rear cover of the display is
perforated and provides better airflow than other displays, it is still important
that you consider room cooling and ventilation.
