PT3285PW Touch Screen Edge-lit LED LCD Monitor USER’S GUIDE www.planar.
The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced,translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission. Windows is a registered trademark of Microsoft, Inc.
Table of Contents Usage Notice Precautions............................................................................................................................. 1 Introduction About PT3285PW ................................................................................................................... 2 Touch Screen for PT3285PW ................................................................................................. 2 Package Overview ....................................................
Usage Notice ! ! Warning - To prevent the risk of fire or shock hazards, do not expose this product to rain or moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. Do: • Turn off the product before cleaning.
Introduction About PT3285PW The PT3285PW is a 31.5" flat panel screen with an active matrix, thin-film transistor (TFT) edge-lit LED LCD. Features include: • Direct Analog signal input • Direct Digital signal input • Active matrix TFT edge-lit LED LCD technology • 1920 x 1080 resolution • 31.5" viewable display area - 16:9 aspect ratio • 31.47 ~ 67.5 KHz horizontal scan • 47 ~ 63 Hz high refresh rate • 0.36375mm x 0.
Package Overview Display USB Cable (A to B) Power Cord VGA Signal Cable Audio-in Cable DVI-D Cable Touch Screen Driver Installation CD-ROM Landing Strip xxxxxxxxx xxxxxxxxx / xxxxxxxxx USER’S GU IDE www.planartou ch.
Installation Product Overview • Front View • Bottom View USB COM OUT COM IN AC IN DVI IN VGA IN Remote Key AUDIO IN AUDIO OUT 4
VESA Mount for Your Monitor This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface standard which defines a physical mounting interface for flat panel monitors, and corresponding with the standards of flat panel monitor mounting devices, such as wall and table arms. The VESA mounting interface is located on the back of your monitor. To mount the monitor on a UL certified swing arm or other mounting fixture, follow the instructions included with the mounting fixture to be used.
Start Your Installation Please follow these instructions so that you can hook up the cables to associated connectors. 1. Lay the display flat on an even surface and take off cable cover as seen in thestep 1 diagram. 2. Connect the cables to the appropriate connectors as seen in the step 2 diagram. 3.
Connecting the Display (Figure 8.1) To setup this display, please refer to the following figure and procedures. 1. 2. Be sure all equipment is turned off. Connect the AC power cord to the power connector on the monitor and the other end into an electrical outlet (8.1). 3. Connect the D-SUB or DVI cable from the display’s VGA input connector to the D-SUB or DVI connector of your host computer and tighten the screws (8.1). 4.
(Figure 8.1) Controlling the PT3285PW monitor via RS-232 C Remote Control (Optional) The PT3285PW monitor can be controlled by connecting a PC with a RS-232C terminal diagramed below: COM In COM Out COM In Note: Two COM Ports are reserved for this option. Before using the remote control function, design a custom firmware based on your own application program and communication protocol. Use null modem cable to enable it.
User Controls Rear Panel Controls Icon Key Name Menu Up Down Select Power OSD Key Menu off status Menu on status Menu appear Menu disappear / return to main item Brightness Main item select up / Adjust up Mute Main item select down / Adjust down Auto Adjust Select sub-item function Power On / Off 9
How to Use the OSD Menus Icon Key Name Menu Up Down Select Power 1. Press the “MENU” button to pop up the “on-screen menu” and press “Up” or “Down” button to select among the six functions in the main menu. 2. Choose the adjustment items by pressing the “Select” button. 3. Adjust the value of the adjustment items by pressing the “Up” or “Down” button. 4. With the OSD menu on screen, press “ Menu” button to return main menu or exit OSD. 5.
On-Screen Display Menus Main OSD Menu: ITEM CONTENT Contrast The monitor luminance level control. Brightness The monitor backlight level control. Auto Adjust Fine-tune the image to full screen automatically. Left/Right Moving screen image horizontal position to left or right. Up/Down Moving screen image vertical position to up or down. Horizontal size The screen image horizontal dot clock adjustment. Fine The screen image pixel phase adjustment.
Appendix Troubleshooting If you are experiencing trouble with the display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. ► Check that all the I/O and power connectors are correctly and well connected as described in the “Installation” section. ► Make sure the pins of the connectors are not crooked or broken. Problem: Partial Image or incorrectly displayed image.
Warning Signal If you see warning messages on your screen, this means that the display cannot receive a clean signal from the computer graphics card. Below are the three kinds of Warning Signal. Please check the cable connections or contact your local dealer or our service center for more information. No Signal This message means that the display has been powered on but it cannot receive any signal from the computer graphics card. Check all the power switches, power cables, and VGA/DVI signal cable.
Product Dimensions 786.1mm 4- R13 480.7mm 69mm Front View 590.0mm 98.1mm 200.0mm 400.0mm 144.1mm 98.
Compatibility Modes Mode Resolution H-Frequency(khz) V-Frequency(hz) IBM VGA 640X480 31.47 60 VESA SVGA 800X600 35.16 56 VESA SVGA 800X600 37.88 60 VESA XGA 1024X768 48.36 60 VESA SXGA 1280X1024 64.00 60 VESA SXGA 1280X960 60.00 60 WXGA+ 1440X900 56.00 60 WSXGA+ 1680X1050 65.20 60 VESA WXGA 1280X768 47.776 60 VESA WXGA 1280X720 44.77 60 VESA WXGA 1366X768 47.71 60 WSXGA+ 1920X1080 67.
Touch Screen Driver Installation The PT3285PW Series is available with USB connection. Please Note: 1. The PT3285PW is Microsoft Windows® HID (Human Interface Device) compatible if you use the USB touch screen interface. No additional software driver is required for general operation of the touch screen. 2. Microsoft Windows® 7 operating system requires 15 seconds to recognize the PT3285PW after connecting the USB cable and power cable. PT3285PW Calibration Tool Install: ! PLEASE NOTE! 1.
Planar Systems, Inc. Customer Service 24x7 Online Technical Support: http://www.planar.com/support 1195 NW Compton Drive Beaverton, OR 97006-1992 Tel: 1-866-PLANAR1 (866-752-6271) or +1 503-748-5799 outside the United States. Hours: 24 hours a day, 7 days a week © 2013 Planar Systems, Inc. 1/13 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
