CRB2295A_U_English.book Page 1 Monday, December 11, 2006 Manual Overview This manual describes information related to the hardware, such as the names of parts for the navigation system or precautions for use. Please read this manual and all other enclosed manuals before using your navigation system. The following issues are described in each chapter: How to use this manual Precautions This chapter describes precautions for the safe use of the navigation system.
CRB2295A_U_English.book Page 2 Monday, December 11, 2006 10:33 AM Precautions Important Safety Information Before using your navigation system, be sure to read and fully understand the following safety information: Information to User Alteration or modifications carried out without appropriate authorization may invalidate the user’s right to operate the equipment. For Canadian model This Class B digital apparatus complies with Canadian ICES-003.
CRB2295A_U_English.book Page 3 Monday, December 11, 2006 ❒ The navigation features of this product (and rear view camera option if purchased) are intended solely as an aid to you in the operation of your vehicle. It is not a substitute for your attentiveness, judgement and care when driving. ❒ Do not operate this navigation system (or the rear view camera option if purchased) if doing so will divert your attention from the safe operation of your vehicle.
CRB2295A_U_English.book Page 4 Monday, December 11, 2006 10:33 AM ➲ Setting the source to rear source ➞ Operation Manual • THE LIGHT GREEN LEAD AT POWER CONNECTOR IS DESIGNED TO DETECT PARKED STATUS AND MUST BE CONNECTED TO THE POWER SUPPLY SIDE OF THE PARKING BRAKE SWITCH. IMPROPER CONNECTION OR USE OF THIS LEAD MAY VIOLATE APPLICABLE LAW AND MAY RESULT IN SERIOUS INJURY OR DAMAGE.
CRB2295A_U_English.book Page 5 Monday, December 11, 2006 10:33 AM Chapter 1 Notes Before Using the System After-sales service for Pioneer products Please contact the dealer or distributor from where you purchased the product for its aftersales service (including warranty conditions) or any other information.
Notes Before Using the System Chapter 1 CRB2295A_U_English.book Page 6 Monday, December 11, 2006 Music recognition technology and related data are provided by Gracenote®. Gracenote is the industry standard in music recognition technology and related content delivery. For more information visit www.gracenote.com.
CRB2295A_U_English.book Page 7 Monday, December 11, 2006 Bluetooth® technology compatibility You can display what is behind the vehicle if connected to a rear view camera (sold separately). ➲ “About rear view camera” ➞ Page 4 Required $12.95 basic monthly XM radio subscription and XM NavTraffic service subscriptions sold separately. XM NavTraffic only available in select markets. Other fees and taxes, including a one-time activation fee, may apply. Subscription fee is consumer only.
CRB2295A_U_English.book Page 8 Monday, December 11, 2006 Notes Before Using the System Chapter 1 About DTS sounds Only digital output of DTS audio is possible. If navigation system’s optical digital outputs are not connected, DTS audio will not be output, so select an audio setting other than DTS.
CRB2295A_U_English.book Page 9 Monday, December 11, 2006 ➲ For details about handing the LCD panel ➞ Page 18 Due to its construction, the viewing angle of the LCD screen is limited. The viewing angle can be increased, however, by using [Brightness] to adjust the black density of the video. When using for the first time, adjust the black density in accordance with the viewing angle to adjust for clear viewing.
Notes Before Using the System Chapter 1 CRB2295A_U_English.
CRB2295A_U_English.book Page 11 Monday, December 11, 2006 10:33 AM Chapter 2 How to Use the Navigation System and Names of the Parts Checking Part Names and Functions This section gives information about the names of the parts and main the features using the buttons. ❒ For more details on operations and limitations of functions, please refer to the Operation Manual.
CRB2295A_U_English.book Page 12 Monday, December 11, 2006 3 V button Press to enter the PICTURE ADJUSTMENT mode. ➲ Operating the Picture Adjustment ➞ Operation Manual How to Use the Navigation System and Names of the Parts Chapter 2 Press and hold to turn off the back light of the LCD panel. To turn on the back light, press this button again. 4 Signal receptor This area receives signals from a remote control (sold separately).
CRB2295A_U_English.book Page 13 Monday, December 11, 2006 ❒ To cancel standby mode, press the V button again, or touch the screen. When Using the Navigation System for the First Time Selecting a Source with the AV button 1 Turn the ignition switch (ACC) ON. The navigation system’s power supply comes on. 2 After the navigation system starts, press the AV button to switch the screen. The navigation map screen changes to the audio source screen. 3 Press the AV button to turn the audio source on.
CRB2295A_U_English.book Page 14 Monday, December 11, 2006 Turning the Source Off • Press the AV button and hold until the source turns off. ❒ This navigation system also can be switched off by turning the ACC (ignition) OFF. 10:33 AM Inserting a disc 1 Press the OPEN CLOSE button. The LCD panel opens, and the disc loading slot appears.
CRB2295A_U_English.book Page 15 Monday, December 11, 2006 ❒ The built-in DVD drive plays one, standard, 12cm or 8-cm (single) disc at a time. Do not use an adapter when playing 8-cm discs. ❒ If you cannot insert a disc completely or if an inserted disc is not recognized, check that the label side of the disc is up. Press the EJECT button to eject the disc, and check the disc for damage before inserting the disc again. ➲ Error messages ➞ Operation Manual Touch [Back].
How to Use the Navigation System and Names of the Parts Chapter 2 CRB2295A_U_English.
CRB2295A_U_English.book Page 17 Monday, December 11, 2006 10:33 AM Appendix When the Hard Disk Drive is Disconnected If there is no hard disk drive due to repair or service, only the Radio source can be operated. The following screen also may appear because the hard disk drive can not run due to low temperature. In such a case, park your vehicle in a safe place and turn the ignition switch off. After the temperature inside the vehicle returns to normal, turn the ignition switch on.
CRB2295A_U_English.book Page 18 Monday, December 11, 2006 Meaning of marks on DVDs The marks below may be found on DVD disc labels and packages. They indicate the type of images and audio recorded on the disc, and the functions you can use. Mark 2 2 • • • Meaning Indicates the number of audio systems. • Indicates the number of subtitle languages. • 10:33 AM scratches, or those that are warped may not play properly. Do not use such discs.
CRB2295A_U_English.book Page 19 Monday, December 11, 2006 About liquid crystal display (LCD) screen • Small black dots or white dots (bright dots) may appear on the LCD screen. These are due to the characteristics of the LCD screen and do not indicate a problem with the navigation system. • At low temperatures, the LCD screen may be dark for a while after the power is turned on. • The LCD screen will be difficult to see if it is exposed to direct sunlight.
CRB2295A_U_English.book Page 20 Monday, December 11, 2006 Specifications Appendix General Rated power source ............ 14.4 V DC (10.8 V to 15.1 V allowable) Grounding system ............... Negative type Maximum current consumption ................................... 10.0 A Dimensions (W ✕ H ✕ D): DIN Chassis ......................... 178 ✕ 100 ✕ 165 mm (7 ✕ 3-7/8 ✕ 6-1/2 in.) Nose.............................. 170 ✕ 96 ✕ 16 mm (6-3/4 ✕ 3-3/4 ✕ 5/8 in.) Weight .................................. 2.
CRB2295A_U_English.book Page 21 Monday, December 11, 2006 10:33 AM FM tuner Frequency range.................. 87.9 MHz to 107.9 MHz Usable sensitivity................. 8 dBf (0.7 µV/75 Ω, mono, S/ N: 30 dB) Signal-to-noise ratio ............ 75 dB (IHF-A network) Distortion.............................. 0.3 % (at 65 dBf, 1 kHz, stereo) 0.1 % (at 65 dBf, 1 kHz, mono) Frequency response ............ 30 Hz to 15 000 Hz (±3 dB) Stereo separation ................
