11. Place door onto Track
Position the door over the opening and slightly tilt the bottom
of the door outward away from the wall. Set the rollers securely
onto the track. Once the door is safely mounted and is secure,
turn the 2 safety spacers 180 degrees towards the wall. This
positions them properly under the track. See Figure 13.
PVC Barn Door Assembly and Track Installation Z Style 42”
2
INCH
2
INCH
1-1/2”
Figure 13
12. Install Handle
Measure up 52” from the bottom of the door and mark that
location. Measure in 2 ¾” in from the edge of the stile and mark
this spot. Drill a hole through the stile at the intersection of these
2 marks. Place the handle (P) on the door and insert one of the
handle bolts into the top hole in the handle. Put the washer and
nut onto the backside of the door and tighten the nut. Do not
tighten fully at this point. Using a level to make sure the handle
is plumb, mark the location of the bottom hole in the handle.
Move the handle aside and drill the second hole through the
stile. Put the remaining bolt through the hole in the handle. Put
the washer and nut onto the backside of the door and tighten
the nut. Use the wrenches provided to fully tighten the bolts and
secure the handle.
See Figure 14.
2
INCH
2
INCH
1-1/2”
13. Install Floor Guide
The Bottom Door guide (V) keeps the door from swinging out-
ward away from the wall. To locate the proper installation posi-
tion in the oor, slide the door into the closed position and mark
the outside edge of the door on the oor. Now place the door
into the open position and mark the inside edge of the door on
the oor. Make sure your guide location is well marked. Make
sure that whether the door is in the open or closed position, that
the door NEVER leaves the Door guide. This is the proper
location for the Door guide. Set the width of the oor guide to
1-1/2”. Slide the door out of the way and place the guide on
the oor in between the 2 marks. Pre-drill holes if necessary for
your oor type. Using a drill and the screws provided, secure the
Door guide to the oor. See Figure 15.
2
INCH
2
INCH
1-1/2”
14. Set Door Stops on Track
Make sure the rubber stoppers are facing inward on each side.
Move the door to the closed position and slide the Door stop
to desired location. Using the provided Allen wrench, tighten
the screws in the door stop to secure it in into place. Then
carefully glide the door into the fully open position and repeat
the steps for the remaining Door stop. See gure 16.
2
INCH
2
INCH
1-1/2”
Figure 14
Figure 15
Figure 16
